AB4D Forum - All Forums

Forum closed, use Issues on GitHub instead

Wed, 01 Apr 2026 13:50:10 +0200

This forum is closed because of problems with sending emails.

Please use Issues or Discussions on the GitHub Ab4d.SharpEngine.Samples repo.

Forum closed, use Issues on GitHub instead

Wed, 01 Apr 2026 13:47:35 +0200

This forum is closed because of problems with sending emails.

Please use Issues or Discussions on the GitHub Ab3d.DXEngine.Wpf.Samples repo.

Forum closed

Wed, 01 Apr 2026 13:46:17 +0200

This forum is closed because of problems with sending emails.

Forum closed, use Issues on GitHub instead

Wed, 01 Apr 2026 13:45:08 +0200

This forum is closed because of problems with sending emails.

Please use Issues or Discussions on the GitHub Ab3d.PowerToys.Wpf.Samples repo.

Forum closed, use Issues on GitHub instead

Wed, 01 Apr 2026 13:44:08 +0200

This forum is closed because of problems with sending emails.

Please use Issues on the GitHub Samples project.

Forum closed, use Issues on GitHub instead

Wed, 01 Apr 2026 13:42:10 +0200

This forum is closed because of problems with sending emails.

Forum closed notice, use Issues on GitHub instead

Wed, 01 Apr 2026 13:35:55 +0200

This forum is closed because of problems with sending emails.

Please use Issues on the GitHub Samples project.

Optimizing Duplicate Model Imports

Fri, 27 Mar 2026 09:18:30 +0100

For the purposes of a simulation built on the DXEngine and PowerToys, a very large number of high-poly models of the same .obj file must be imported on a low-spec system.

I have a Model class which encapsulates WPF's ModelVisual3D and is constructed using the Model3D returned by an instance of AB3D's ReaderObj. An optimization specific to this use-case has already been implemented, whereby we obtain this Model faster by using the CloneCurrentValue extension on Model3Ds generated from a .obj file we've previously imported from. This has the benefit of running our turing machine over the tape in memory rather than that of the disk, but still performs quite poorly on startup. Is there a known/supported method of obtaining many independent Model3Ds from one .obj I am overlooking here?

Allow MultiLineNode.Material setter to change in runtime

Wed, 04 Mar 2026 12:52:47 +0100

Hi

I have an scenario where I need to create many dimension lines that share same material that can react to my application settings, so I allocate much less resources by having single material for them all

However, I also need to Paint/Wash the lines when hovering or selecting them

Material property is init-only so I need a different material for each object to accomplish that

Could it be possible to make public setter to update material in runtime?

Fatal signal when running Ab4d sample app on Samsung phone with Android 16

Fri, 20 Feb 2026 13:27:34 +0100

I am getting issues with SharpEngine on Samsumg phone with Android 16. If I run the latest Ab4d sample app (3.2.9509) it crashes with Fatal Signal 11. The app runs fine on an Android 16 emulator.

Are there any workarounds you can suggest- e.g. CreateEngineOptions?

The sample app crashes in the e.Surface.Canvas.DrawBitmap(_renderedSceneBitmap, info.Rect); inside SharpEngineSceneView.CanvasViewOnPaintSurface

02-20 14:15:17.739 V/XGL (27083): ----------------------------------------------------------------------
02-20 14:15:17.739 V/XGL (27083): SUMD version compiled date = 2025-06-11 14:47 - KST
02-20 14:15:17.739 V/XGL (27083): SUMD version revision number = 1fc295b0d2
02-20 14:15:17.739 V/XGL (27083): SUMD version info = Driver version: 24.0.545, git hash: 1fc295b0d2
02-20 14:15:17.739 V/XGL (27083): ----------------------------------------------------------------------
02-20 14:15:17.739 V/XGL (27083): Entering: Create
02-20 14:15:17.743 V/XGL (27083): Exiting: Create
02-20 14:15:17.861 D/VRI[MainActivity]@c2164b1(27083): reportNextDraw android.view.ViewRootImpl.performTraversals:5443 android.view.ViewRootImpl.doTraversal:3924 android.view.ViewRootImpl$TraversalRunnable.run:12903 android.view.Choreographer$CallbackRecord.run:1901 android.view.Choreographer$CallbackRecord.run:1910
02-20 14:15:17.862 D/VRI[MainActivity]@c2164b1(27083): Setup new sync=wmsSync-VRI[MainActivity]@c2164b1#0
02-20 14:15:17.862 I/VRI[MainActivity]@c2164b1(27083): Creating new active sync group VRI[MainActivity]@c2164b1#1
02-20 14:15:17.864 D/VRI[MainActivity]@c2164b1(27083): registerCallbacksForSync syncBuffer=false
02-20 14:15:17.876 W/monodroid-assembly(27083): Shared library 'libjnigraphics.so' not loaded, p/invoke 'AndroidBitmap_lockPixels' may fail
02-20 14:15:17.877 I/amples.maui.ios(27083): hiddenapi: Accessing hidden field Landroid/graphics/Bitmap;->mNativePtr:J (runtime_flags=0, domain=platform, api=unsupported) from Lcrc648e35430423bd4943/SKCanvasView; (domain=app) using JNI: allowed
02-20 14:15:18.868 E/SurfaceSyncGroup(27083): Failed to receive transaction ready in 1000ms. Marking SurfaceSyncGroup(wmsSync-VRI[MainActivity]@c2164b1#0) as ready
02-20 14:15:18.869 I/SurfaceSyncGroup(27083): checkIfSyncIsComplete: Callers=android.window.SurfaceSyncGroup.markSyncReady:281 android.window.SurfaceSyncGroup.lambda$addTimeout$6:860 android.window.SurfaceSyncGroup.$r8$lambda$ButZILC1krkx4FHXNaBT92Z1Qt8:0 android.window.SurfaceSyncGroup$$ExternalSyntheticLambda3.run:0 android.os.Handler.handleCallback:995
02-20 14:15:18.869 D/SurfaceSyncGroup(27083): Successfully finished sync id=wmsSync-VRI[MainActivity]@c2164b1#0
02-20 14:15:18.869 D/VRI[MainActivity]@c2164b1(27083): reportDrawFinished seqId=0
02-20 14:15:18.871 E/SurfaceSyncGroup(27083): Failed to receive transaction ready in 1000ms. Marking SurfaceSyncGroup(VRI[MainActivity]@c2164b1#1) as ready
02-20 14:15:18.871 I/SurfaceSyncGroup(27083): checkIfSyncIsComplete: Callers=android.window.SurfaceSyncGroup.markSyncReady:281 android.window.SurfaceSyncGroup.lambda$addTimeout$6:860 android.window.SurfaceSyncGroup.$r8$lambda$ButZILC1krkx4FHXNaBT92Z1Qt8:0 android.window.SurfaceSyncGroup$$ExternalSyntheticLambda3.run:0 android.os.Handler.handleCallback:995
02-20 14:15:18.871 D/SurfaceSyncGroup(27083): Successfully finished sync id=VRI[MainActivity]@c2164b1#1
02-20 14:15:25.531 I/GSC (27083): SID[0] : ef82d8ce10ab7c83, Kind: 1, time : 29.523 ms
02-20 14:15:25.537 I/GSC (27083): SID[1] : 05ebe144822b6758, Kind: 0, time : 5.742 ms
02-20 14:15:25.543 I/GSC (27083): SID[2] : 5a197a1cc83b561c, Kind: 1, time : 1.654 ms
02-20 14:15:25.562 I/GSC (27083): SID[3] : 710015f16afb9a1f, Kind: 2, time : 18.198 ms
02-20 14:15:25.596 I/GSC (27083): SID[4] : 8bba210ad7cf2e91, Kind: 2, time : 32.451 ms
02-20 14:15:36.492 F/libc (27083): Fatal signal 11 (SIGSEGV), code 2 (SEGV_ACCERR), fault addr 0x7bd8f78000 in tid 27083 (amples.maui.ios), pid 27083 (amples.maui.ios)

InputEventsManager.PointerExited not fired

Thu, 12 Feb 2026 11:19:58 +0100

Hi,

i'm testing out the SharpEngine for a upcoming project with Avalonia and WPF.
During this testing i noticed that the PointerExited event doesn't seem to fire when using Avalonia or WPF framework.
All other mouse events like PointerEntered or PointerMoved are working correctly when moving the mouse over the SharpEngine control.
I've also tried it with your Samples application where it also doesn't seem to fire this event.

Is this a bug or do i have to implement this event manually by routing it from WPF/Avalonia to the InputEventsManager?

Avalonia TabControl causes MainSceneView to be disposed

Sat, 07 Feb 2026 06:56:18 +0100

I am having an unexpected behaviour with the Avalonia TabControl.

The Scene is initialized when the control is first shown, but if you tab to another control and come back the Scene is disposed. When you try to move the camera, the following exception is thrown:

Code:
  at Ab4d.SharpEngine.SceneNodes.SceneNode.Update()

  at Ab4d.SharpEngine.Scene.Update(Boolean forceUpdateAll)

  at Ab4d.SharpEngine.Scene.GetClosestHitObject(Ray ray, SceneNode rootSceneNode, HitTestOptions customHitTestOptions)

  at Ab4d.SharpEngine.SceneView.GetClosestHitObject(Ray ray, HitTestOptions customHitTestOptions)

  at Ab4d.SharpEngine.Utilities.CameraController.GetRotationCenterPositionFromPointerPosition(Vector2 pointerPosition, Boolean calculatePositionWhenNoObjectIsHit)

  at Ab4d.SharpEngine.Utilities.CameraController.UpdateRotationCenterPosition(Vector2 pointerPosition, Boolean calculatePositionWhenNoObjectIsHit)

  at Ab4d.SharpEngine.Utilities.CameraController.StartCameraRotation(Vector2 pointerPosition)

  at Ab4d.SharpEngine.Utilities.ManualPointerCameraController.StartPointerProcessing(Vector2 pointerPosition, PointerButtons pressedButtons, KeyboardModifiers keyboardModifiers)

  at Ab4d.SharpEngine.Utilities.ManualPointerCameraController.ProcessPointerMoved(Vector2 pointerPosition, PointerButtons pressedPointerButtons, KeyboardModifiers keyboardModifiers)

  at Ab4d.SharpEngine.AvaloniaUI.PointerCameraController.♔(Object ♔, PointerEventArgs ♔)

  at Avalonia.Interactivity.Interactive.g__InvokeAdapter|8_0[TEventArgs](Delegate baseHandler, Object sender, RoutedEventArgs args)

  at Avalonia.Interactivity.Interactive.<>c__8`1.b__8_1(Delegate baseHandler, Object sender, RoutedEventArgs args)

  at Avalonia.Interactivity.EventRoute.RaiseEventImpl(RoutedEventArgs e)

  at Avalonia.Interactivity.EventRoute.RaiseEvent(Interactive source, RoutedEventArgs e)

  at Avalonia.Interactivity.Interactive.RaiseEvent(RoutedEventArgs e)

  at Avalonia.Input.MouseDevice.ProcessRawEvent(RawPointerEventArgs e)

  at Avalonia.Controls.TopLevel.<>c.b__150_0(Object state)

  at Avalonia.Threading.Dispatcher.Send(SendOrPostCallback action, Object arg, Nullable`1 priority)

  at Avalonia.Controls.TopLevel.HandleInput(RawInputEventArgs e)

  at Avalonia.Win32.WindowImpl.AppWndProc(IntPtr hWnd, UInt32 msg, IntPtr wParam, IntPtr lParam)

  at Avalonia.Win32.WindowImpl.WndProcMessageHandler(IntPtr hWnd, UInt32 msg, IntPtr wParam, IntPtr lParam)

  at Avalonia.Win32.Interop.UnmanagedMethods.DispatchMessage(MSG& lpmsg)

  at Avalonia.Win32.Win32DispatcherImpl.RunLoop(CancellationToken cancellationToken)

  at Avalonia.Threading.DispatcherFrame.Run(IControlledDispatcherImpl impl)

  at Avalonia.Threading.Dispatcher.PushFrame(DispatcherFrame frame)

  at Avalonia.Threading.Dispatcher.MainLoop(CancellationToken cancellationToken)

  at Avalonia.Controls.ApplicationLifetimes.ClassicDesktopStyleApplicationLifetime.StartCore(String[] args)

  at Avalonia.Controls.ApplicationLifetimes.ClassicDesktopStyleApplicationLifetime.Start(String[] args)

  at Avalonia.ClassicDesktopStyleApplicationLifetimeExtensions.StartWithClassicDesktopLifetime(AppBuilder builder, String[] args, Action`1 lifetimeBuilder)

  at AB4D.TabControlIssue.Program.Main(String[] args) in D:\Development\Ab4d.SharpEngine.Samples-main\TabControlSample\Program.cs:line 12

I created a project at GitHub to illustrate the issue

https://github.com/MichaelFCoyle/AB4D.TabControlIssue

In the main application I am working with a different exception is thrown because I am adding points to the root node but basically the MainSceneView, Scene, SceneView and RootNode are all disposed.

Is there guidance where I can re-create the scene in code every time the TabControl is shown?

OBJ file not drawing correctly

Tue, 03 Feb 2026 04:21:31 +0100

I'm testing out Ab4d.SharpEngine to use for a project and we plan to get a 4-seat license if I can demonstrate it will work for us. One of my main needs is going to be rendering OBJ files. I tested with an OBJ file of my house.

This is what I get in Ab4d:

This is what the house should look like. I'm rendering this in a program I work on called xLights. We use the tinyobjloader for loading the OBJ file. All our code is freeware on GitHub under xLights Sequencer. But I can't use that code for this new project. We want to use Avalonia and Ab4d already has nice integration.

Performance with multiple views

Tue, 13 Jan 2026 16:13:02 +0100

Hi,

I am writing an Avalonia MDI application where it is possible to have many windows created at one time, each of which uses it's own SharpEngine view control.
I notice that after say 5 windows are opened, performance in subsequent windows degrades sharply. This is not too surprising given the amount of resources that needs to be allocated to each view

So far: I am sharing a single VulkanDevice across all renderers and have already set supersampling to 1 - the latter certainly improves performance over multiple screens but at some quality cost of course.

Given that most of these views won't actually be *visible* at the same time, I am looking forguidance on what the best strategy is for trying to reduce resource use in my scenario. I do need to be able to let the user open multiple views, but of course the total screen area (even if all are visible) will never exceed the screen dimensions. Is there a recommended way to release the heaviest GPU assets whilst views are not visible that will allow quick resumption when the user reverts to the view?

thanks!

CameraQuickZoomStarted & CameraQuickZoomEnded not fired

Fri, 31 Oct 2025 15:18:46 +0100

I think CameraQuickZoomStarted & CameraQuickZoomEnded events are not fired for MouseCameraController

I know I can subscribe to MouseCameraController.Camera.PropertyChanged, but there I can't know when zoom is done
